Podab ProLine TS63 E
Drying cabinets

ProLine TS63 E

EvacuationHeat pump

The ProLine drying cabinet series offer versatile, energy-efficient drying solutions for various industries. Designed to handle everything from workwear and uniforms to PPE, they provide gentle, effective drying without mechanical wear. Ideal for professional and industrial use, ensures fast, reliable results while preserving fabric quality.

The ProLine TS63 E drying cabinet offers gentle and energy-efficient drying technology, perfect for all textiles and PPE. The ProLine drying cabinets are utilizing a drying process without mechanical action to prevent damage and in turn extend the lifespan of your laundry. With a spacious 34.7 cu ft capacity, it efficiently dries various textiles and accessories. Equipped with versatile interior options like swinging rails or ventilated shelves, it ensures flexibility to accommodate specific drying requirements.

location_onFind a reseller
Product number: 131090

Main data

Product type
Drying cabinet
Product name
ProLine TS63 E
Product no.
131032
Warranty
Three-year limited
Type
Air vented
Hanging length, ft/m
52.5/16
Capacity, sets of turnout gear
4
Capacity (dry weight), lb/kg
18/8
Interior capacity, cu ft/l
34.7/983
Energy consumption, kWh
3.0
Drying capacity, oz/min / g/min
2.2/62
Noise emission, dB(A)
62
Language, #
8
Prepared for payment system
Standard
Reversable swinging hanging rail system
Standard
Connection cable
Included
Drying time (normal temperature), min
42
Residual moisture before drying, %
43
Residual moisture after drying, %
0

Electrical Installation

Supply voltage, V
3~N/400V/50Hz
Electric heating, W
6000
Electric fan, W
300
Total effect, W
6300
Protection, A
10
Cable length, in/mm
98/2500

Specifications

Outer: WxDxH, in
47x25.2x74
Outer: WxDxH, mm
1200x640x1870
Shipping dimensions: WxDxH, in
49x28x81
Shipping dimensions: WxDxH, mm
1250x700x2050
Weight, lb
320
Weight, kg
145
Shipping weight, lb
351
Shipping weight, kg
159

Ventilation

Outlet exhaust, Øin/mm
4.9/125
Outlet airflow, cfm/m³/h
135/230
Max pressure drop, psf/Pa
1.46/70
Max airflow (at 0% pressure), cfm/m³/h
200/340

Manuals

Product sheet

Key features

  • Capacity & design

    • 18 lbs dry weight

    • 37.7 cu ft interior

    • 52.5 ft hanging length

    • Rotating hanging rail (180°) with doors opening 190°

  • Advanced drying system

    • Automatic & manual programs

    • Preset start time

    • Temperature & humidity tracking

    • Electric heated air drying

  • Efficiency & safety

    • Energy-efficient

    • Gentle drying without mechanical action

    • Double overheat protection

    • Cool down mode at program end

  • Durability & versatility

    • Powder-coated galvanized steel

    • Sturdy construction

    • Interior lighting

    • Versatile drying options for delicate and hard-to-dry textiles

Delicate drying technology

The ProLine TS63 E and HP drying cabinets provide an innovative, energy-efficient solution for drying textiles with care. Featuring a gentle drying process without mechanical action, they are ideal for delicate or hard-to-dry garments that shouldn't be tumble dried. With the TS63 E and HP, you can eliminate concerns about damaging fabrics, offering a safe and effective alternative for all your drying needs.

Flexible drying solutions

The ProLine TS63 E and HP can be fitted with a swinging rail system for easy access, customized with a single bar for standard hangers, or equipped with ventilated shelves for drying accessories that cannot be hung. This versatility offers maximum flexibility to meet your specific drying requirements.

Maximized energy efficiency

The ProLine TS63 E and HP are highly energy-efficient, reducing both operational costs and environmental impact. Their innovative design ensures optimal performance while minimizing energy use, making them a sustainable choice for any laundry operation.

The ProLine TS63 E and HP are equipped with a Humidity Tracking System (HTS) that uses sensors to monitor both temperature and humidity. This system detects moisture levels and automatically halts the drying process once the laundry reaches optimal dryness, ensuring both time and energy efficiency.

Humidity and temperature tracking
